Rustic,
yet refined style

RSF Mobile Home Hangtag - E

Available in Canada only.

Temporarily unavailable for sale in the USA – pending EPA certification.

Renowned for quality construction and market leading performance, the Pearl 3600 is certified at 1.7g/hr. Like all RSF fireplaces the Pearl 3600 is built to last a lifetime and is an excellent addition to any home. The Pearl is crafted with the perfect combination of refined, yet rustic styling. Capable of heating 1,500 square feet, the Pearl can be outfitted with an optional Heat Dump blower to ensure your comfort. Excess heat from the fireplace can be drawn to the basement or an adjacent room with the flick of a switch.

This fireplace is certified for use with 6″ ICC Model EXCEL chimney only.

Documents and Specs

The Pearl 3600B

Note: The installation manual should always be used for the precise planning and accurate installation of your fireplace.

GENERAL SPECIFICATIONS
Outside Dimensions36 3/8″ W X 43 3/4″ H X 24 1/8″ D
Firebox Dimensions

2.04 cu ft

Based on overall firebox dimensions, firebox volume per certification testing is 1.6 cu ft

Shipping weight455lbs
Glass viewing size258 in2
20 ¼” W x 11 ½” H + arch
Firewood LengthTested with cribwood, can accept up to 18″ logs
Chimney6″ Excel
Door FinishBlack
Outside Air

4″, meets R2000

All RSF models come equipped to accept a 4″ outside air duct, a 5″ can also be used. All models can also be installed to operate using room air.

Mobile Home ApprovedYES
PERFORMANCE
Emission  Certification 1.7 g/h

CSA B415.1.22 emission

BTU Output 19,077 BTU/h

Based on EPA certification testing using cribwood and calculations from CSA B415:22

BTU Maximum TBC BTU/h

Based on engineering calculations using firebox volume, efficiency, loading density (12lb/cu ft for hardwood), average humidity, reloading interval, type of installation, etc.

Heating Capacity 800 to 1,500 ft2

Depends primarily on wood quality, ambient air temperature and building heat loss.

Optimal Efficiency 75.3%

Low Heating Value (LHV) using CSA B415.1:22 calculations.

Average Efficiency 70%

High Heating Value (HHV) using CSA B415.1:22 calculations.

Average CO 1.3 g/min

Carbon Monoxide (CO), using data from EPA crib wood testing

Specs and CAD
CATALOGS AND BROCHURES
OWNER’S MANUALS
WARRANTY
exploded view
