THE PEARL 3600

Rustic,
yet refined style

Learn more about
Mobile / Manufactured Home Certification

Available in Canada only.

Temporarily unavailable for sale in the USA – pending EPA certification.

Renowned for quality construction and market leading performance, the Pearl 3600 is certified at 1.7g/hr. Like all RSF fireplaces the Pearl 3600 is built to last a lifetime and is an excellent addition to any home. The Pearl is crafted with the perfect combination of refined, yet rustic styling. Capable of heating 1,500 square feet, the Pearl can be outfitted with an optional Heat Dump blower to ensure your comfort. Excess heat from the fireplace can be drawn to the basement or an adjacent room with the flick of a switch.

This fireplace is certified for use with 6″ ICC Model EXCEL chimney only.

Gallery

Pearl_3600_Fireplace_stone_finishAug2020

The Pearl 3600 – Rustic, yet refined style.

Available Options

Gravity Vent Kit

The gravity vent kit uses natural convection to distribute the heat generated by the fireplace to the same floor and/or floors above the fireplace.

Gravity Vent Kit – Rectangular

The gravity vent kit uses natural convection to distribute the heat generated by the fireplace to the same floor and/or floors above the fireplace.

Internal Blower

The internal blower kit will increase the circulation of heated air in the room where the fireplace is installed.

Heat Dump

The Heat Dump Kit contains all the parts necessary to circulate a moderate amount of heat from your fireplace to another room with a small fan.

Masonry Chimney Adapter

This adapter will attach to the liner with 3 stainless steel rivets (provided) and to the EXCEL chimney with 3 screws (provided).

Door Gasket Replacement Kit ⅝’’

This kit (FO-GRK8) includes the gasket and high temperature sealant required to change the door gasket on your fireplace.

Compare all fireplaces and options

view heat distribution options

Documents and Specs

The Pearl 3600B

Note: The installation manual should always be used for the precise planning and accurate installation of your fireplace.

GENERAL SPECIFICATIONS
Outside Dimensions	36 3/8″ W X 43 3/4″ H X 24 1/8″ D
Firebox Dimensions	2.04 cu ft Based on overall firebox dimensions, firebox volume per certification testing is 1.6 cu ft
Shipping weight	455lbs
Glass viewing size	258 in² 20 ¼” W x 11 ½” H + arch
Firewood Length	Tested with cribwood, can accept up to 18″ logs
Chimney	6″ Excel
Door Finish	Black
Outside Air	4″, meets R2000 All RSF models come equipped to accept a 4″ outside air duct, a 5″ can also be used. All models can also be installed to operate using room air.
Mobile Home Approved	YES

PERFORMANCE
Emission Certification	1.7 g/h CSA B415.1.22 emission
BTU Output	19,077 BTU/h Based on EPA certification testing using cribwood and calculations from CSA B415:22
BTU Maximum	TBC BTU/h Based on engineering calculations using firebox volume, efficiency, loading density (12lb/cu ft for hardwood), average humidity, reloading interval, type of installation, etc.
Heating Capacity	800 to 1,500 ft2 Depends primarily on wood quality, ambient air temperature and building heat loss.
Optimal Efficiency	75.3% Low Heating Value (LHV) using CSA B415.1:22 calculations.
Average Efficiency	70% High Heating Value (HHV) using CSA B415.1:22 calculations.
Average CO	1.3 g/min Carbon Monoxide (CO), using data from EPA crib wood testing
