Available in Canada only.
Temporarily unavailable for sale in the USA – pending EPA certification.
The Focus 3600’s versatile size, large viewing space, 1.7gr/h emissions and high efficiency make it ideal for retrofits and new installations alike.
Power and performance in a small package. At 2.04 cubic feet, the firebox of the Focus 3600 is the same size as the average wood stove, except it takes up less floor space and has a contemporary, built-in design. Despite its compact size, the Focus 3600 offers a large viewing space and generates an impressive amount of heat. With such a small footprint, the Focus not only saves space in the home, but it can be installed virtually anywhere.
This fireplace is certified for use with 6″ ICC Model EXCEL chimney only.
Gallery
The Focus 3600 – Certified at 1.7 g/hr
Gravity Vent Kit
The gravity vent kit uses natural convection to distribute the heat generated by the fireplace to the same floor and/or floors above the fireplace.
Gravity Vent Kit – Rectangular
The gravity vent kit uses natural convection to distribute the heat generated by the fireplace to the same floor and/or floors above the fireplace.
Internal Blower
The internal blower kit will increase the circulation of heated air in the room where the fireplace is installed.
Heat Dump
The Heat Dump Kit contains all the parts necessary to circulate a moderate amount of heat from your fireplace to another room with a small fan.
Masonry Chimney Adapter
This adapter will attach to the liner with 3 stainless steel rivets (provided) and to the EXCEL chimney with 3 screws (provided).
Door Gasket Replacement Kit ⅝’’
This kit (FO-GRK8) includes the gasket and high temperature sealant required to change the door gasket on your fireplace.
Compare all fireplaces and options
view heat distribution options
Documents and Specs
Focus 3600B
Note: The installation manual should always be used for the precise planning and accurate installation of your fireplace.
| GENERAL SPECIFICATIONS | |
|---|---|
| Outside Dimensions | 34 3/8″ W X 40 5/8″ H X 22 1/2″ D |
| Firebox Dimensions | 2.04 cu ft Based on overall firebox dimensions, firebox volume per certification testing is 1.6 cu ft |
| Shipping weight | 398 lbs |
| Glass viewing size | 241 in2 20 ½” W x 11 ¾” H |
| Firewood Length | Tested with cribwood. Can accept up to 18″ logs. |
| Chimney | 6″ Excel |
| Door Finish | Black |
| Outside Air | 4″, meets R2000 All RSF models come equipped to accept a 4″ outside air duct, a 5″ can also be used. All models can also be installed to operate using room air. |
| Mobile Home Approved | YES |
| PERFORMANCE | |
|---|---|
| Emission Certification | 1.7 g/h CSA B415.1:22 emission |
| BTU Output | 19,077 BTU/h Based on EPA certification testing using cribwood and calculations from CSA B415.1:22 |
| BTU Maximum | 50,000 BTU/h Based on engineering calculations using firebox volume, efficiency, loading density (12lb/cu ft for hardwood), average humidity, reloading interval, type of installation, etc. |
| Heating Capacity | 800 to 1,500 ft2 Depends primarily on wood quality, ambient air temperature and building heat loss. |
| Optimal Efficiency | 75.3% Low Heating Value (LHV) using CSA B415.1:22 calculations. |
| Average Efficiency | 70% High Heating Value (HHV) using CSA B415.1:22 calculations. |
| Average CO | 1.3 g/min Carbon Monoxide (CO), using data from EPA crib wood testing |
